Rugged 12 Buttons Can Bus Keypads For Construction Agriculture Heavy Duty
| Feature | Description |
|---|---|
| Communication | 1×CAN (Supports CANopen / J1939 / Custom CAN) |
| Key Layout Options | 12 Keys |
| Output | 1×DOH |
| Backlight | White LED, brightness adjustable |
| Status Indicator | RGB Three-color LED /12pcs of Highlight LED RGB Monocolor LED(10 Green+2 Red) |
Product Description
Sonnepower rugged 12-button CAN bus keypad is designed for construction machinery, agricultural equipment, and heavy-duty vehicles. Featuring IP65/IP67 protection and a wide operating temperature range of -40 to 85°C, it ensures stable performance in harsh environments.
It supports a working voltage of 8–32V and includes high-response silicone keys, CAN communication, and a high-side output. With a compact structure (available in 129×100×31.2mm or 111.1×68.1×37.6mm), it fits easily into space-constrained dashboards.
Ideal for applications such as garbage trucks, drilling rigs, and mining vehicles, this CAN-based control panel offers a customizable key icon layout, making it a reliable and efficient operator interface for mobile machinery systems.
Specification
Dimensions
SPM-KEYP-A12
SPM-KEYP-Q12
SPM-LEDP-C12
Application
-
Garbage Compactor Trucks
The 12-button CAN bus keypad controls compaction, lifting, and door operations with precise and responsive input, designed to withstand dusty and rainy outdoor conditions. -
Drilling Rigs
Used for hydraulic system control and safety alerts on drilling rigs, this keypad endures long hours of outdoor operation with its waterproof, dustproof, and high-temperature resistant design. -
Mining Trucks
Suitable for harsh mining environments, featuring shock and dust resistance. It manages load monitoring, braking systems, and lighting controls to enhance safety and efficiency. -
Round Balers
Provides reliable start, stop, and function switching controls for balers, with responsive keys that improve operational accuracy and productivity in agricultural tasks. -
Agricultural Tractors and Harvesters
Controls multiple functions including hydraulic lifts, attachments, and lighting systems. Designed for extended outdoor use, resisting sun, wind, and dust exposure. -
Municipal Sweepers and Sprayers
Operates spraying, water pumps, and brush speeds, with a protective design that ensures stable use in wet and dusty urban environments.
